Sony E-mount lenses

E-mount

3:2

Approx. 24.2 megapixels

Approx. 25.0 megapixels

APS-C type (23.5 x 15.6mm), Exmor CMOS sensor

Charge protection coating on optical filter and ultrasonic, vibration mechanism

JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)

L: 6000 x 4000 (24M), M: 4240 x 2832 (12M), S: 3008 x 2000 (6.0M)

L: 6000 x 3376 (20M), M: 4240 x 2400 (10M), S: 3008 x 1688 (5.1M)

L: 4000x4000 (16M), M: 2832x2832 (8.0M), S: 2000x2000 (4.0M)

Wide: horizontal 12,416 x 1,856 (23M), vertical 5,536 x 2,160 (12M), Standard: horizontal 8,192 x 1,856 (15M), vertical 3,872 x 2,160 (8.4M)

RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)

13 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key, Soft Focus (High/Mid/Low), HDR Painting (High/Mid/Low), Rich-tone Monochrome, Miniature (Auto/Top/Middle (H)/Bottom/Right/Middle (V)/Left), Watercolor, Illustration (High/Mid/ Low)

Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))

Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset

Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))

sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Color

Yes

-

XAVC S, AVCHD format Ver. 2.0 compliant

XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264

XAVC S: LPCM 2ch, AVCHD: Dolby Digital (AC-3) 2ch, Dolby Digital Stereo Creator

xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS Color

Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta), Soft High-key

Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))

Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset

XAVC S 4K: 3840 x 2160 (30p, 100M), 3840 x 2160 (24p, 100M), 3840 x 2160 (30p, 60M), 3840 x 2160 (24p, 60M), XAVC S HD: 1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920 x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080(30p, 16M), AVCHD: 1920 x 1080 (60i, 24M, FX), 1920 x 1080 (60i, 17M, FH)

XAVC S 4K: 3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M), XAVC S HD: 1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920 x 1080 (25p, 50M), 1920 x 1080 (50p, 25M), 1920 x 1080 (25p, 16M), AVCHD:1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH)

NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps,

NTSC mode: 1920 x 1080 (60p, 30p, 24p), PAL mode: 1920 x 1080 (50p, 25p)

Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 (Approx.9Mbps)), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), Auto Slow Shutter, REC Control, Clean HDMI Info. (ON/OFF selectable), Gamma Disp. Assist

3840 x 2160 (30p), 3840 x 2160 (25p), 3840 x 2160 (24p), 1920 x 1080 (60p), 1920 x 1080 (60i), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), YCbCr 4:2:2 8bit / RGB 8bit

Yes

Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro (M2), SD memory card, SDHC memory card (UHS-I compliant), SDXC memory card (UHS-I compliant), microSD memory card, microSDHC memory card, microSDXC memory card

Multi slot for Memory Stick Duo/SD memory card

Long exposure NR: On/Off, available at shutter speeds longer than 1 sec., High ISO NR: Normal/Low/Off

Auto/ ISO 100 to 102400

Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent (Warm White / Cool White / Day White / Daylight) / Flash /Underwater/ Color Temperature (2500 to 9900K) & color filter (G7 to M7 (57-step), A7 to B7 (29-step)) / Custom

Yes (G7 to M7,57-step)(A7 to B7,29-step)

Yes

Yes (Shut. Halfway Down/ Cont. Shooting/ Off)

3 frames, H/L selectable

Fast Hybrid AF (phase-detection AF/contrast-detection AF)

Exmor CMOS sensor

425 points (phase-detection AF) / 425 points (contrast-detection AF)

EV-2 to EV20 (ISO100 equivalent with F2.0 lens attached)

AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus

Wide (425 points (phase-detection AF), 425 points(contrast-detection AF)) / Zone / Center / Flexible Spot (S/M/L) /Expanded Flexible Spot/ Tracking ( Wide / Zone / Center / Flexible Spot (S/M/L)/Expanded Flexible Spot)

Eye-start AF (only with LA-EA2 or LA-EA4 attached (Sold separately)), Object Tracking, Eye AF (Right/Left Eye Select), AF micro adjustment with LA-EA2 or LA-EA4 (Sold separately), Predictive control, Focus lock, Swt.V/H AF Area, AF Area Regist., Circ. of Focus Point

Yes (with Built-in LED type)

Approx. 0.3- approx. 3.0m (with E PZ 16-50mm F3.5-5.6 OSS lens attached)

phase-detection

1200-zone evaluative metering

Exmor CMOS sensor

EV-2 to EV20 (at ISO100 equivalent with F2.0 lens attached)

Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight

+/- 5.0EV (1/3 EV, 1/2 EV steps selectable)

Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, or 1.0 EV increments.

Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)

AUTO (iAuto/Superior Auto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M),Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M)), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M)), Sweep Panorama, Scene Selection

Still images: ISO 100-32000 (ISO numbers up to ISO 102400 can be set as expanded ISO range.), AUTO (ISO 100-6400, selectable lower limit and upper limit), Movies: ISO 100-32000 equivalent, AUTO (ISO 100-6400, selectable lower limit and upper limit)

Portrait, Sports Action, Macro,Landscape, Sunset, Night Scene, Hand-held Twilight, Night Portrait, Anti Motion Blur

1.0 cm (0.39 type) electronic viewfinder (color)

2 359 296 dots

Auto/Manual (5 steps between -2 and +2)

Manual (5 steps)

100%

Approx. 1.07x (35mm camera equivalent: Approx. 0.70x) with 50mm lens at infinity, -1m^-1

-4.0-+3.0 m^-1

Approx. 23mm from the eyepiece lens, 21.4mm from the eyepiece frame at -1m^-1 (CIPA standard)

NTSC mode: STD 60fps / HI 120fps, PAL mode: STD 50fps / HI 100fps

Graphic Display, Display All Info., No Disp. Info., Digital Level Gauge, Histogram

7.5cm (3.0-type) wide type TFT

921 600 dots

Yes

Manual (5 steps between -2 and +2), Sunny Weather mode

Up by approx. 180 degrees, Down by approx. 74 degrees

On/Off

Yes

Yes Focus Magnifier (5.9x, 11.7x)

Yes (selectable level + range or lower limit as custom setting)

Yes (Level setting: High/Mid/Low/Off, Color: White/Red/Yellow/Blue)

WhiteMagic, Grid Line (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie Marker (Center/Aspect/Safety Zone/Guideframe)

Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histogram, For viewfinder, Monitor Off

-

Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)

Smart zoom (Still images): M: Approx. 1.4x, S: Approx. 2x, Digital zoom (Still images): L: Approx. 4x, M: Approx. 5.7x, S: Approx. 8x, Digital zoom (Movie): Approx. 4x

Modes: Face Priority in AF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces Priority (On/Off), Face registration, Max. number of detectable: 8

Yes

Interval Recording, Smile Shutter: Smile shutter (selectable from 3 steps), Touch Shutter, Touch Focus: Yes (Touch Focus/Touch Pad/Touch Tracking), ISO AUTO Min. SS, Bright Monitoring, Set File Name, Help guide, Area Setting, Shop Front Mode, Zoom Ring Rotate

-

Electronically-controlled, vertical-traverse, focal-plane type

Still images:1/4000 to 30 sec, Bulb, Movies: 1/4000 to 1/4 (1/3 steps), up to 1/50 in AUTO mode (up to 1/25 in Auto slow shutter mode)

1/160 sec.

Yes (ON/OFF)

Yes (ON/OFF)

Not supported (image stabilisation supported on lens)

Built-in flash

6 (in meters at ISO 100)

16mm (focal-length printed on the lens body)

Pre-flash TTL

+/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)

3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments.

Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless control,Hi-speed sync

Approx. 4 sec

Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash compatible with Auto-lock accessory shoe

Yes

Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)

Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket

Continuous shooting: Hi+: 11 fps, Hi: 8 fps, Mid: 6 fps, Lo: 3 fps

JPEG Extra fine L: 99 frames, JPEG Fine L: 115 frames, JPEG Standard L: 116 frames, RAW: 46 frames, RAW&JPG: 44 frames

10 sec. delay/5 sec. delay/2 sec. delay/Continuous self-timer (3 frames after 10 sec. delay/5 frames after 10 sec. delay/3 frames after 5 sec. delay/5 frames after 5 sec. delay/3 frames after 2 sec. delay/5 frames after 2 sec. delay)/Bracketing self-timer (Off/2 sec. delay/5 sec. delay/10sec. delay)

Yes

Single (with or without shooting information Y RGB histogram & highlight/shadow warning), 12/30-frame index view, Enlarged display mode (L: 16.7x, M: 11.8x, S: 8.3x, Panorama (Standard): 19.2x, Panorama (Wide): 29.1x), Auto Review (10/5/2 sec,Off), Image orientation (Auto/Manual/Off selectable), Slideshow, Panorama scrolling, Folder selection (Date/ Still/ AVCHD/XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete, Protect, Rating, Disp Cont Shoot Grp

Mass-storage, MTP, PC remote

Yes

Yes (NFC forum Type 3 Tag compatible),One-touch remote,One-touch sharing

Wi-Fi Compatible, IEEE 802.11b/g/n (2.4GHz band), View on Smartphone, Remote control via Smartphone, Send to Computer, View on TV

Yes (Bluetooth Standard Ver. 4.1 (2.4GHz band))

HDMI micro connector (Type-D), BRAVIA Sync(Control for HDMI), PhotoTV HD, 4K movie output/4K still image PB

Yes

Yes (3.5 mm Stereo minijack)

-

-

-

-

Yes

Built-in stereo microphone or XLR-K2M/XLR-K1M/ECM-XYST1M(sold separately)

Built-in, monaural

Exif Print, Print Image Matching III, DPOF setting

Custom key settings, Programmable Setting (Body 3 sets /memory card 4 sets), My Menu, My Dial, Reg Cust Shoot Set

Peripheral Shading, Chromatic Aberration, Distortion

One rechargeable battery pack NP-FW50

Approx. 360 shots (Viewfinder) / Approx. 410 shots (LCD monitor) (CIPA standard)

Approx. 70 min (Viewfinder) / Approx. 75 min (LCD monitor) (CIPA standard)

Approx. 125 min (Viewfinder) / Approx. 125 min (LCD monitor) (CIPA standard)

Yes

AC Adaptor AC-PW20 (sold separately)

Still images: approx. 2.4W (with E PZ 16-50mm F3.5-5.6 OSS lens attached), Movies: approx. 3.5W (with E PZ 16-50mm F3.5-5.6 OSS lens attached)

Still images: approx. 2.1W (with E PZ 16-50mm F3.5-5.6 OSS lens attached), Movies: approx. 3.5W (with E PZ 16-50mm F3.5-5.6 OSS lens attached)

Yes

32 - 104 degrees F / 0 - 40 degrees C

Approx. 403g / Approx. 14.3 oz.

Approx. 120.0mm x 66.9mm x 59.7mm, Approx. 120.0mm x 66.9mm x 49.9mm (from grip to monitor)/Approx. 4 3/4 x 2 3/4 x 2 3/8 inches, Approx. 4 3/4 x 2 3/4 x 2 inches (from grip to monitor)
